Máy quét mã vạch Zebra Symbol DS2278 (Bluetooth, 10m, 1D & 2D)

Chi tiết sản phẩm

Máy quét mã vạch Zebra Symbol DS2278

- Máy đọc mã vạch Zebra (Symbol) DS2278 sử dụng công nghệ Bluetooth® không dây trong phạm vi 10m.

- Hỗ trợ đọc mã vạch 1D & 2D.

- Cảm biến điểm ảnh: 640 x 480 pixels.

- Pin li-ion: 2400mAh.

- Có thể chịu được va đập tốt khi rơi từ độ cao 1.5 mét.

- Tiêu chuẩn chống bụi: IP52.

- Cổng giao tiếp: USB.

- Option: RS232, Keyboard (CALL).

- Ứng dụng: Siêu thị, nhà sách, nhà thuốc, bệnh viện, nhà kho...

Đặc tính kỹ thuật

Model	DS2278
Physical
Dimensions	17.5 (H) x 6.6 (W) x 9.0 (D) cm
Weight	214g
Input Voltage Range	4.5 to 5.5 VDC Host Powered; 4.5 to 5.5 VDC External Power Supply
Supported Host Interfaces	USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
Keyboard Support	Supports more than 90 international keyboards
User Indicators	Direct Decode Indicator; good decode LEDs; Rear view LEDs; beeper (adjustable tone and volume)
Bluetooth Radio	Standard Bluetooth Version 4.0 with BLE
Performance
Motion Tolerance (Handheld)	Up to 5 in./13 cm. per second for 13 mil UPC
Swipe Speed (Hands-Free)	Up to 30.0 in./76.2 cm. per second for 13 mil UPC
Light Source	Aiming Pattern: Linear 624nm Amber LED
Illumination	(2) 645nm Super-Red LEDs
Imager Field of View	32.8° H x 24.8° V Nominal
Image Sensor	640 x 480 pixels
Minimum Print Contrast	25% minimum reflective difference
Skew/Pitch/Roll Tolerance	+/- 65°; +/- 65°; 0-360°
Minimum Element Resolution	Code 39 - 4.0 mil; Code 128 - 4.0 mil; Data Matrix - 6.0 mil; QR Code - 6.7 mil
Environment
Operating Temperature	32.0° to 122.0° F/0.0° to 50.0° C
Storage Temperature	-40.0° to 158.0° F/-40.0° to 70.0° C
Humidity	5% to 95% RH, non-condensing
Drop Specification	Designed to withstand multiple drops at 5.0 ft./1.5 m to concrete
Tumble Specification	Designed to withstand 250 tumbles in 1.5 ft./.5 m tumbler
Environmental Sealing	IP52
Ambient Light Immunity	0 to 10,000 Foot Candles/0 to 107,600 Lux
Decode Capabilities
1D	Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma)
2D	PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Han Xin, Postal Codes

- Bảo hành: 12 tháng.
